1.Liquid silicone rubber for coating and coating molding
(1)Basic model:HY-1310A/B
(2) Main features and benefits
This product is a two-component liquid silicone rubber vulcanized with a platinum catalyst. It has the characteristics of easy operation, high strength, and good bonding with the substrate.
(3) Product Features
?Excellent strength and good adhesion to the substrate
?Rapid vulcanization at medium temperature, good fluidity and easy operation
?Non-toxic and environmentally friendly
?Good degassing performance, easy to color
?Good heat resistance and weather resistance
?
(4) Typical uses
Silicone trademark or product pressing cloth
(5) Package
20kg/200kgstandardbucket,A:B=1:10 or 2:100
(6) Typical physical properties
?
?
| index | Reference standard | unit | HY-1310B |
| Exterior | transparent | ||
| viscosity | DIN 53019 | Pas | 50 |
| density | DIN53 479A | g/cm3 | 1.08 |
| hardness | DIN53 505 | A | 35 |
| Tensile Strength | DIN53 504 S2 | MPa | 5.0 |
| Tear strength | ASTM D624 Die C | KN/m | ≥ 15 |
| Elongation | DIN53 504 S2 | % | 300 |
| vulcanization conditions | 140℃*10min | ||
(7) Remarks
The above typical data are for reference only and cannot be used as a basis before use. The specific molding process conditions should depend on the specifications and models of the product. You can also contact our company's engineering department.
?
?
